ES3 Series

About ES3 Series

Applications Processing machines injection molding machines packaging machines precision textile machines largescale warehousing logistics systems

Specifications

CPU

 32bit highspeed processor

 Builtin IO points 32  48  64  80

Program capacity 64k steps

General register 64k words

Commun-ication ports RS485  2 Ethernet  1 and CANopen DS301  1

Builtin SD interface Micro SD

IO points 256 points 256 inputs  256 outputs

4 highspeed counters maximum frequency 200 kHz for each counter

4axis 8 points highspeed position output at 200 kHz

Supports a total of 8axis CANopen position outputs

Supports IEC611313 programming LD ST SFC and CFC

Robust Industrial Performance

The ES3 Series VFD is designed for demanding industrial automation tasks offering reliable motor control and maximizing operational efficiency Its sturdy aluminium alloy body ensures durability while the intelligent cooling maintains optimal performance in challenging conditions ranging from 10C to 50C Adjustable speed regulation 01 Hz to 400 Hz and up to 150 overload capacity for 60 seconds ensure robust adaptability

Advanced Control  UserFriendly Operation

Equipped with a DSPbased processor the ES3 Series VFD offers precise digital control and highspeed processing Users can easily program settings via the keypad or remote interface while the large multifunction LED panel clearly displays essential operational data Remote monitoring and adjustment are supported through RS485 connectivity further streamlining industrial automation processes

Comprehensive Protection  High Efficiency

Safety is a cornerstone of the ES3 Series design featuring builtin overload short circuit protection and an inbuilt braking unit for models up to 22 kW The highgrade EMC filter ensures minimal harmonic distortion With high efficiency and customizable cable lengths this VFD provides secure adaptable and reliable control for a wide spectrum of application requirements

FAQs of ES3 Series

Q How can I program the ES3 Series Variable Frequency Drive for my specific application

A Programming the ES3 Series VFD is straightforward you can use the onboard keypad or connect through the remote interface The DSPbased control allows precise parameter adjustments and the multifunction LED panel provides clear operational feedback

Q What types of motors are compatible with the ES3 Series

A This VFD is suitable for threephase squirrel cage induction motors handling power ratings from 075 kW to 75 kW and voltage inputs of 380V415V AC 15 making it ideal for various industrial settings

Q When should I use the inbuilt braking unit feature

A The inbuilt braking unit is available in models up to 22 kW It is recommended for applications requiring rapid stopping or deceleration of the load such as conveyor systems or hoists

Q Where can the ES3 Series VFD be installed

A Designed for panel mounting the ES3 Series can be installed in control cabinets within industrial environments provided ambient humidity does not exceed 90 RH noncondensing and temperatures remain between 10C and 50C

Q What is the process for monitoring and controlling the drive remotely

A Remote monitoring and control are facilitated via RS485 connectivity enabling integration with industrial automation systems The drive supports realtime adjustments fault diagnostics and operational data access remotely

Q How does the builtin EMC filter benefit the user

A The integrated EMC filter minimizes electrical harmonics and electromagnetic interference promoting stable operation protecting sensitive equipment and ensuring compliance with industrial safety standards

Q What safety features are included in the ES3 Series VFD

A Safety is assured through overload protection short circuit protection and an automatic shutdown mechanism The device also maintains high efficiency under load and can operate up to 150 overload for up to 60 seconds ensuring equipment and operator safety
