Our company is presenting clients superior quality Junction box that finds its main application in various places. It is a container for different electrical connections that are usually used to conceal them from deter tampering. The offered box is available in different designs and sizes to fulfill our clients' diverse requirements. Further, our vendors manufacture and design this Junction box using quality approved raw material with the help of modern techniques. We offer this box to our reputed clients as per their needs at affordable rates.
Features:
Additional Information:
Junction Boxes are made of halogen-free ABS, which has high resistance to chemicals and atmospheric agents. By virtue of the design they offer IP 65 protection with the help of silicon rubber gasket in EPDM. They are available with plain walls, nipples and membrane. Junction-Box are offered with press-on lids, screw lids and hinged lids. Stainless steel screws are also available on request for lid fastening. Choice of grey colour lid or transparent lid is also available on request.
Technical Data
Material |
ABS |
Colour |
Grey |
Screw |
Zinc Plated and Chromate Passivated |
Gasket |
Silicon Rubber EPDM |
Lid |
Grey colour/ transparent |
Standard |
IEC 670, CEI 23-48 |
Protection Class |
IP 65 |
Approvals |
CE |
Grey Lid
Cat No |
Internal Dimension (mm) LXWXH |
M003. PL |
80X80X40 |
M005. PL |
100X100X50 |
M006. PL |
100X100X65 |
M007. PL |
120X75X50 |
M007. XPL |
110X80X60 |
M008. PL |
150X110X70 |
M009. PL |
190X145X70 |
M0010. PL |
240X190X90 |
M0011. PL |
240X190X110 |
M0011. XPL |
240X180X100 |
M012. PL |
310X230X115 |
Grey High Top Lid
Cat No |
Internal Dimension (mm) LXWXH |
M008.CA.G |
150X110X135 |
M009.CA.G |
190X145X135 |
M010.CA.G |
240X190X160 |
M011.CA.G |
240X180X170 |
M012.CA.G |
310X230X160 |
M014.CA.G |
380X300X180 |
M015.CA.G |
460X380X180 |
Grey Hinged Lid
Cat No |
Internal Dimension (mm) LXWXH |
M009.A. PL |
190X140X70 |
M010.A. PL |
240X190X90 |
M012.A. PL |
305X225X125 |
M014.A. PL |
380X300X120 |
M015.A. PL |
460X380X120 |
Transparent Lid
Cat No |
Internal Dimension (mm) LXWXH |
M003. PK |
80X80X40 |
M005. PK |
100X100X50 |
M006. PK |
100X100X65 |
M007. PK |
120X75X50 |
M007. XPK |
110X80X60 |
M008. PK |
150X110X70 |
M009. PK |
190X145X70 |
M010. PK |
240X190X90 |
M011. PK |
240X190X110 |
M011. XPK |
240X180X100 |
M012. PK |
310X230X115 |
Transparent Hinged lid
Cat No |
Internal Dimension (mm) LXWXH |
M009.A.PK |
190X140X70 |
M010.A.PK |
240X190X90 |
M012.A.PK |
305X225X125 |
M014.A.PK |
380X300X120 |
M015.A.PK |
460X380X120 |
Transparent High Top Lid
Cat No |
Internal Dimension (mm) LXWXH |
M008.CA.K |
150X110X135 |
M009.CA.K |
190X145X135 |
M010.CA.K |
240X190X160 |
M011.CA.K |
240X180X170 |
M012.CA.K |
310X230X160 |
M014.CA.K |
380X300X180 |
M015.CA.K |
460X380X180 |
