Delta VFD AC Drive/ VFD1A5MS43ANSAA

About Delta VFD AC Drive/ VFD1A5MS43ANSAA

Standard Models (0-599 Hz) Without EMC Filter Part Number: Delta VFD1A5MS43ANSAA Nominal Input VAC: 480 Volts AC Input Range VAC: 460 Volts AC HP: .50 HP Amps (HD): 1.5A Amps (ND): 1.8A Input Phase : 3 PH Operator Controls: Sold Seperately, See Accessories Brake Type : DC Injection; Dynamic Braking Motor Control-Max Level: Open Loop Vector-(Sensorless Vector) Closed Loop: NO AC Line Regenerative: NO Dynamic Braking Trans: Included Enclosure Rating: IP20 Frame Size: A4 Height: 5.04 Inches Width: 2.68 Inches Depth: 5.08 Inches Net Weight: 4 Lbs. Deltas MS300 series is a standard compact vector control drive that inherits Deltas superior drive technology. It supports both IM and PM motor control for application flexibility and provides STO safety mechanism. Also built-in various essential functions, including PLC capacity for simple programming needs, a communication slot for various communication cards, and a USB port to make data uploads and downloads fast and easy. Saving space, reducing setup and wiring time, while providing high efficiency and stability system, all included in the MS300 series with drive size reduced up to 40%. Delta VFD MS300 Micro Drive Accessories

Enhanced Protection and Reliability

Equipped with multiple protection features such as overload, short circuit, over voltage, under voltage, and over temperature safeguards, the Delta VFD1A5MS43ANSAA drive offers reliable operation even in demanding environments. Integrated fault indication and an alarm buzzer allow for quick troubleshooting, helping minimize downtime in critical applications.


User-Friendly Interface and Control

The drive features a 7-segment LED display, offering clear parameter visualization. With six programmable digital inputs and two programmable relay outputs, it accommodates a wide range of control strategies. Start/stop methods include keypad, remote terminal, or external switch, enabling flexible and convenient operation tailored to your installation needs.


Versatile Application and Advanced Performance

Designed for pumps, fans, conveyors, HVAC systems, and machine tools, this AC Drive provides both manual and automatic torque boost, multiple acceleration/deceleration curves, and sensorless operation. Its RS-485 communication port supports seamless integration into modern automation systems, making it a top choice for dealers, distributors, and end-users across India.
